TS Marketplace: COV AB Vans Wagon Pack 01

Into the 1960’s British Railways mainly provided 12T vehicles for the covered carriage of general merchandise, the exception being those vans intended to work on the train ferry services to Europe. While nearly all these vehicles were fitted with continuous train brakes, they were vacuum braked & in conjunction with their short wheelbase of 10ft, this limited them to running at 45mph.

In the mid-1960’s British Rail started to make the move towards using air brakes and after Merry Go Round coal hoppers and container flats had been successfully introduced, attention was turned towards providing new vans. A few experimental designs were tried out before a definitive production design appeared.

Ashford Works began delivering these new production series vans from the middle of 1969 to Diagram 1/248. These vehicles were a major step forward from the vacuum braked fleet, with a carrying capacity of 29T and 2 sliding doors of nearly 16ft long each. With a 20ft 9in wheelbase and Double Link suspension, they could run at 60mph maximum with a Gross Load of 45T, or could reach 75mph if the load was reduced to 35T Gross. They were fitted with Air-brakes that operated on wheel mounted discs and also had a through Vacuum pipe, to allow them to run with existing freight stock.

The 209 vehicles that formed Lot 3685 were given the Telegraphic Code COV AB and were delivered in Freight Brown livery with the corporate BR Double Arrow. A yellow disc with the letters ABN in black was also applied to denote they were intended to be used on the Air Braked Network, which was a precursor to the more familiar Speedlink network of the late 1970’s & 1980’s. For some unknown reason, 20 of these vans were fitted with end ventilators.

When TOPS coding was introduced, the vans with end vents (200100 - 200119) were coded as VAB, the remainder (200000 - 200099 & 200120 - 200208) were to be VBB. Some depots misapplied the codes, so some of the vehicles without vents appeared with the incorrect VAB code, though the correct code was applied at a later date.

The COV AB 46t Vans Wagon Pack 01 for Train Simulator features:

Freight Brown, Maroon and Railfreight Flame Red & Grey liveries (with livery-correct auto-numbering)

Clean and weathered variations

Physics to recreate loaded as well as empty versions.

Intelligent oil tail lamps (Mk1 Battery flashing lamps on the weathered Railfreight livery)

Dynamically assigned works plate details, dependant on vehicle number

4 random options of lettering applicable to each variation

The pack includes a user manual with further details about the rolling stock and the customising of some of the features when using the wagons in scenarios.
